Jebao ( ELW-M ) Series WaveMaker Controller/Wi-Fi Mobile phone, Dual Control

Features:

• Wi-Fi+ manual control system, a variety of wave-making modes and functions, can basically meet the waveforms required by users.
• Using wireless linkage control to realize synchronous operation between water pumps. It can be controlled by one, and can be controlled remotely.
• Using low-voltage DC variable frequency water pump to ensure the personal safety of users
• Simple operation panel to realize complex dynamic seawater function
• The direction of water flow can be adjusted according to needs.
• Wide voltage input (AC100~240V 50/60Hz), suitable for a variety of power grids, and
• It can avoid the influence of voltage fluctuation on wave making.

Installation Notes:1. It is basically suitable for all fish tank sizes, and the maximum absorption fish tank glass thickness is 15mm.

Specifications:

ELW-3M

• Power: 1.5W-4.5W
• Voltage: 110V-240V 50/60Hz
• Water Flow: 750L/H-2500L/H
• Ejection: 40mm
• Tank size: <40cm
• Tank Thickness: <8mm

ELW-5M

• Power: 2.5W-7.5W
• Voltage: 110V-240V 50/60Hz
• Water Flow: 900L/H-3000L/H
• Ejection: 52mm
• Tank size: <60cm
• Tank Thickness: <8mm

ELW-10M

• Power: 3W-10W
• Voltage: 110V-240V 50/60Hz
• Water Flow: 1200L/H-4000L/H
• Ejection: 57mm
• Tank size: <60cm
• Tank Thickness: <8mm

ELW-20M

• Power: 6W-20W
• Voltage: 110V-240V 50/60Hz
• Water Flow: 3000L/H-10000L/H
• Ejection: 66mm
• Tank size: 60-100cm
• Tank Thickness: <12mm

ELW-30M

• Power: 9W-30W
• Voltage: 110V-240V 50/60Hz
• Water Flow: 3900L/H-13000L/H
• Ejection: 70mm
• Tank size: 100-120cm
• Tank Thickness: <15mm
